Build digitally!

Use the Hawle CAD/BIM data

Several of our Hawle products are available for free download on our website as BIM data. You can download the BIM data in your preferred format and integrate it into your CAD planning software.

To access our CAD/BIM data, registration on the Hawle portal is required. Once registered, you will have access to the BIM data. These can be identified by the cube icon displayed under the technical specifications of the respective product.

More than 120 file formats in 2D or 3D are available. For the following products, CAD/BIM data is already available in all languages.

WATER Pipework construction

WATER Plant Construction

Chapter A: Flange sliders, shaped parts

4000, Flange slider, PN 16

4017, Flange slider, PN 25

4019, Interchangeable slider incl. loose flanges, tension strength, PN 16

4150, Flange slider reduced, PN 16

7800, Handwheel

8500, Flange pipe, PN 16

8510, Flange-T-piece, PN 16

8520, Flange-cross, PN 16

8530, Flange curved section 90°, PN 16

8540, Flange curved section 45°, PN 16

8550, Flange reduction, PN 16

8580, Intermediate ring with connection, PN 16

Chapter B: Flaps

9940, Butterfly valve with manual lever, type AW, PN 16

9941, Butterfly valve with gearbox, type AW, PN 16

9942, Butterfly valve with manual lever, type LT, PN 16

9943, Butterfly valve with gearbox, type LT, PN 16

9967, Butterfly valve PRO-Klappe® with handwheel, incl. loose flanges, hgh tensile, for system construction, PN 16

9970, Butterfly valve HAWLE, PN 16

Chapter C: Flange connections, seals

3102, Fixed flanges with PE nozzle, special, PN 16/25

7100, Dual-chamber flange for cast pipes, PN 16

7110. Dual-chamber flange for cast pipes, thrust protected, PN 16

7130, Dual-chamber flange for steel pipes, PN 16

7150, Dual-chamber flange for steel pipes, thrust protected, PN 16

8000, Blank flange, PN 16

8100, Threaded flange, PN 16

8110, XR reduction flange, PN 16

8200, Seal with steel insert, PN 16

Chapter E: Regulating valves, dirt traps

1090, Orifice for installation between flanges, type B

1500, Pressure reducing valve

2001, Dirt trap, PN 10/16

2002, Dirt trap, PN 10/16/25/40

2011, Dirt trap, PN 25

Chapter F: Aeration/ventilation valves

9870, Aeration/ventilation valve 1"

9870., Aeration and ventilation valve 2"

Chapter G: Acessoiries for reservoir

9120, Pipe support, height 225 till 300 mm

9121, Pipe support, height 300 till 450 mm

9122, Pipe support, height 450 till 600 mm

9123, Pipe support, height 600 till 750 mm

9124, Pipe support, height 750 till 900 mm

9126, Pipe support, height 100 till 150mm

Chapter H: Waste water slider

2603, House-connection-sewage slider, PN 10

4013, Sewage slider incl. loose flanges, tension strength, PN 10

4503, Plug-in sleeve-waste water slider BAIO, PN 10
